Closed loop control system

In the field of precision motion control, closed loop control systems are indispensable for achieving high levels of accuracy and reliability across a variety of applications. While the concept applies to many engineering disciplines, this guide specifically focuses on the closed-loop control of electromechanical servo systems – the high-performance integration of motors, drives and stages that power modern automation. These systems empower engineering teams in high-tech manufacturing and R&D by enabling precise adjustments based on real-time feedback.

Whether you are stabilizing a laser for semiconductor inspection or managing the delicate force required for wire bonding, the architecture of your servo loop is the difference between success and failure. This article explains the fundamentals of closed loop control systems in electromechanical applications, their components and their critical role in ensuring your system reaches its target state.

What is a closed loop in a control system?

A closed loop control system is a type of control system that continuously monitors actual output and compares it to the desired input command. In the context of an electromechanical servo system, this means the controller does not simply tell a motor to move; it verifies that the motor has moved to the exact location requested.

This feedback mechanism allows the system to make necessary adjustments to ensure that the output remains as close to the desired value as possible. Without this closed loop, a controller cannot compensate for "plant unknowns" or unpredictable disturbances like friction and sensor noise.

The primary components of a closed loop electromechanical system include:

• Sensor: Measures the specific output of the system, such as a linear encoder for position or a load cell for force.
• Controller: Compares the measured feedback to the commanded trajectory and determines the necessary adjustments.
• Motor or Actuator: The electromechanical muscle that implements the adjustments based on the controller's output.

How does a closed-loop control system work?

The feedback loop’s core function is to subtract the measured feedback signal from the desired input to generate an "error signal.” The controller’s algorithm processes this error to generate the actuating signal – typically current or voltage – that drives the plant (the motor and load).

In electromechanical servo systems, this process is often broken down into specific loops that control different physical properties:

• Program: The desired output is set, which acts as the reference point.

• Measurement: The sensor measures the actual output, typically with respect to a position (e.g., linear or rotary displacement).

• Comparison: The controller compares the actual output to the commanded output (e.g., the controller commands a position of 100mm from a reference point and measures a position of 99.999mm).

• Compensation: If there is a discrepancy (also known as error), the controller sends a signal to the motor or actuator to compensate for the error adjustments.

• Feedback: The new commanded adjusted output is measured again, and the cycle repeats.

Through this process, the closed loop control system transfer function describes how changes in the input affect the output, allowing for precise control and adjustments.

The role of feedback in closed loop systems is crucial for improving precision. By continuously monitoring the output and making real-time adjustments, these systems can significantly enhance accuracy in various applications.

In electromechanical servo systems, this accuracy is achieved through specific feedback loops that target different physical properties:

• Position Loops: The most common form of feedback, position loops use high-resolution sensors (such as linear encoders) to ensure the load reaches a specific geometric coordinate. This loop compensates for mechanical errors, ensuring sub-micron positioning accuracy.

• Velocity Loops: Often nested within the position loop, velocity feedback monitors the speed of the actuator. By controlling the rate of change, this loop provides necessary damping to the system, acting like a shock absorber to prevent oscillation and ensure smooth motion profiles.

• Force Loops: Controlling force is difficult because it often involves very small movements and low currents where friction is dominant. A force loop adjusts the current to maintain a precise pressure rather than a position, which is critical during the "touchdown" phase where an actuator makes contact with a delicate part.

How do closed-loop systems enhance accuracy in motion control?

The role of feedback in closed loop systems is crucial for improving precision. By continually monitoring the output and making real-time adjustments, these systems can significantly enhance accuracy in various applications.

Advantages of closed loop systems in electromechanical environments include:

• Increased Precision: Continuous feedback allows for sub-micron position adjustments, essential in high-tech manufacturing.
• Disturbance Rejection: The system can adapt to changes in external conditions, such as cable drag or vibration from nearby machinery.
• Resonance Management: Complex mechanical systems often behave like a two-mass model where the load oscillates relative to the motor. Closed-loop control allows engineers to filter these resonances using notch filters to stabilize the motion.

Examples of applications where this accuracy is critical include:

• Semiconductor Fabrication: Where gear-driven rotary stages and air-bearing systems must position wafers with nanometer-level accuracy.
• Medical Devices: Where force feedback ensures safety during automated procedures or testing.

What type of controller is commonly used in closed loop systems?

One of the most popular types of controllers used in closed loop systems is the Proportional-Integral-Derivative (PID) controller. This is the industry standard control law for electromechanical servos.

Functions and advantages of PID controllers include:

• Proportional Gain: Adjusts the output proportionally to the error. Increasing this gain generally leads to a faster rise time but increases system oscillation.
• Integral Gain: Eliminates residual steady-state error by integrating the error over time. This creates a "phase bubble" in the frequency response that helps the system lock onto its target.
• Derivative Gain: Predicts future error based on its rate of change, effectively adding damping to the system to reduce overshoot.

For high-performance systems, engineers also use Feed-Forward Control, which provides the most authority in the loop by predicting the required current to move a load, leaving the PID loop to handle only minor disturbances.

Is open loop or closed loop better?

Choosing between open-loop and closed-loop systems depends on the specific application and requirements.

Closed-Loop Systems

• Benefits: High accuracy, error correction and the ability to handle "plant unknowns," where physical parameters change during operation.
• Drawbacks: More complex and potentially higher cost due to the need for encoders and feedback cabling.

Open-Loop Systems

• Benefits: Simplicity and lower cost.

• Drawbacks: Lack of feedback leads to potential inaccuracies and an inability to correct for lost steps or friction.

How do I know if I need a closed-loop control system?

When determining whether a closed-loop control system is necessary for your electromechanical application, consider the following factors:

• Precision Requirements: If your application demands high accuracy (sub-micron or nanometer), a closed loop system is essential.

• Dynamic Environments: Systems subject to unpredictable disturbances, such as varying payloads or friction, require feedback to maintain stability.

• Safety and Error Tolerance: Applications that cannot tolerate errors, such as medical devices or expensive semiconductor wafers, require closed loop systems for real-time corrections.

Specific use cases include:

• Fatigue Testing: Where linear motors must maintain precise force amplitude over millions of cycles.

• Laser Processing: Where Position Synchronized Output (PSO) uses feedback to fire lasers at exact physical coordinates regardless of velocity.

What factors should I consider when evaluating closed-loop control system components?

When evaluating components for a closed-loop control system, consider the following key factors:

• Sensor Accuracy: The precision or resolution of the sensor directly affects the system's overall performance.

• Controller Type: Choose a controller that suits your application needs, such as PID for precise control.

• Actuator Responsiveness: The actuator must be capable of making rapid adjustments based on feedback.

• Compatibility: Ensure that components can integrate seamlessly with existing systems.

Importance of Component Performance

High-quality components contribute to the closed-loop control system transfer function, ensuring that the system operates efficiently and accurately.
